Industrial Mini PC
Meegopad-Windows Mini PC/MEEGOPAD C2J
Contact: Elaine  Email:elaine@meegopad.cn     Mobile:0086-15889685436     skype: lichen0000lichen1
Specification www.meegopad.cn
General
Style Industrial Mini PC
OS  Windows10/11/Linux
CPU/GPU
CPU/GPU Intel Alder Lake N100/N95/N200/N300, Intel®ElkhartLakeJ 6426/J6413
CPU Frequency
Turbo Frequency
Core Quad Core
GPU
Storage
Ram DDR4 SODIMMx1,maixmum support 16GB
Storage 1x M.2 2280NVME
1x 2.5inch HDD/SDD
1xMSATA
Expand Storage
Network Communication
WiFi M.2 WiFi Slot*1
Lan 4 x RJ45 Intel i225V/i226V,Support network wake
Bluetooth Support BT moudle(integrated with WiFi)
Sim Card N/A
I/O Ports
RJ45 4 x RJ45 Intel i225V/i226V,Support network wake
HDMI HDMI 2.0 *1 support 4K @60Hz
DP DP 1.4*1 support 4K @60Hz
COM 1 x DB9 RS-232 + 1 x 4P Phoenix terminal RS-485
DC DC port*1 12V
USB 4*USB2.0, 2*USB3.0
LED Power LED*1, HDD LED*1
Atenna port dual, for wifi
Feature Key Power On/Off
Power Adapter
Power Adapter Input 100V-240V 50/60Hz Output 12V 3A
Characteristics
fan low consumption, fanless
  One-key restore,diskless startup,watchdog
Install Way By vesa or desk
Other Function
Auto Boot Support
Wake On Lan Support
Diskless Boot Support
Resume by Alarm Support
Install Way By vesa or desk
Physical Characteristics
Working Tempeturate (-20)~60 (SSD/mSata), 0-50 (HDD)
Sotrage Tempeturate (-30)~70
Relative Hnmidity 10%~90%@30 Non-Condensing
Size 135*127*38.7MM
Weight 1KG
Material  Aluminum
Remark:                                                                                                                                                         Metal Housing, Suitable size for cooling
