C6D

If you want to know more about our product,please sent email to us.
General

Style 12*12cm MAINBOARD / CORE SERIES
OS Windows7/Windows8/Windows10
CPU/GPU
Chip Intel Chip
  I3 8005U:Broadwell/CPU Clock Speed 2.0G,Turbo Boost(NO)/HD Graphics 5500/Support DDR3L
  I5 8250U:Broadwell/CPU Clock Speed 2.20G,Turbo Boost 2.70G/HD Graphics 5500/Support DDR3L
  I7  8350U:Broadwell/CPU Clock Speed 1.60G,Turbo Boost 2.70G/HD Graphics 6000/Support DDR3L
CPU i3 5005U:Broadwell/CPU Clock Speed 2.0G,Turbo Boost(NO)/HD Graphics 5500/Support DDR3L
i5 5200U:Broadwell/CPU Clock Speed 2.20G,Turbo Boost 2.70G/HD Graphics 5500/Support DDR3L
i5 5250U:Broadwell/CPU Clock Speed 1.60G,Turbo Boost 2.70G/HD Graphics 6000/Support DDR3L
i7 5500U:Broadwell/CPU Clock Speed 2.40G,Turbo Boost 3.00G/HD Graphics 5500/Support DDR3L
MACHINE with WIFI+VESA+POWER ADAPTER+HDD CABLE+PACKING
i3 6100U:Skylake/CPU Clock Speed 2.30G,Turbo Boost(NO)/HD Graphics 520/SupportDDR4L
i5 6200U:Skylake/CPU Clock Speed 2.30G,Turbo Boost 2.8G/HD Graphics 520/Support DDR4L
i7 6500U:Skylake/CPU Clock Speed 2.50G,Turbo Boost 3.10G/HD Graphics 520/Support DDR4L
MACHINE with WIFI+VESA+POWER ADAPTER+HDD CABLE+PACKING
i3 7100U:Kabylake/CPU Clock Speed 2.40G,Turbo BoostNO),HD Graphics 620/Support DDR4L
i5 7200U:Kabylake/CPU Clock Speed 2.50G,Turbo Boost 3.10GHD Graphics 620/Support DDR4L
i7 7500U:Kabylake/CPU Clock Speed 2.70G,Turbo Boost 3.50GHD Graphics 620/Support DDR4L
MACHINE with WIFI+VESA+POWER ADAPTER+HDD CABLE+PACKING
Celeron dual core 2955U:Kabylake,CPU Clock Speed1.40G,Turbo Boost (NO),HD Graphics 4000,Support DDR3L
Celeron dual core 3755U:Broadwell,CPU Clock Speed1.70G,Turbo BoostNO),HD Graphics 4000,Support DDR3L
Pentium dual core 3556U:Broadwell,CPU Clock Speed1.70G,Turbo BoostNO),HD Graphics 4000,Support DDR3L
Pentium dual core 3805U:Broadwell,CPU Clock Speed1.90G,Turbo BoostNO),HD Graphics 4000,Support DDR3L
Pentium dual core 3905U:Broadwell,CPU Clock Speed2.0G,Turbo Boost2.0GHD Graphics 5500,Support DDR17L
i3 4010U:Haswell/CPU Clock Speed 1.70G/HD Graphics 4400/Support DDR3L
i5 4200U:Haswell/CPU Clock Speed 1.60G/Turbo Boost 2.60G/HD Graphics 4400/Support DDR3L
i7 4500U:Haswell/CPU Clock Speed 1.80G/Turbo Boost 3.00G/HD Graphics 4400/Support DDR3L
MAINBOARD+CPU+CASENo other accessories
Graphics Card Intel Core Graphics Card
Audio ALC962
Storage
Hard Disk M.2 *1  ; SATA *1
Memory DDR4 2133/2400Maximun Support 64GB (Dual Ram Slot)
Network Communication
WiFi 300Mbps Wireless LAN; Wifi Port *1;
Wired LAN RTL8111 1000M
I/O Ports
HDMI 1*HDMI Port
Data 2*USB2.0/ 4*USB3.0
LAN 1*LAN Port
VGA 1*VGA Port
Audio 1*AUDIO; 1*MIC
Option 2*COM Port
Feature Key PC Power On/OffPower Indicator
Power
Power  12V-5A
Fan
Fan Intelligent Small Fan
Physical Characteristics
Dimension 13.5*13*4cm
Weight 1.5KG
Case All Aluminium Frame; All Aluminium Case for Cooling
Color Silver White/Black/Customized
PACKAGE includeMAINBOARD+CPU+MEMORY+HARD DISK+WIFI+POWER ADAPTER+PACKING
