Meegopad-Windows Mini PC/MEEGOPAD JL6 |
Specification |
www.meegopad.cn |
General |
 |
Style |
Industrial Mini PC |
OS |
Windows7/8/10/Linux |
CPU/GPU |
CPU/GPU |
Intel® i3 i5 i7/J1900 |
Core |
Quad Core |
GPU |
|
Storage |
Ram |
1*SO-DIMM,DDR3L/ DDR4, Maximum 32GB |
Storage |
1*SerialATA, ·1*MINI-SATA |
Expand Storage |
|
Network Communication |
WiFi |
Optional |
Lan |
Intel WGI211AT *6,Support network wake |
Bluetooth |
BT optional |
I/O Ports |
RJ45 |
WGI211AT Gigabit 2.0GHZ*6 |
COM |
RJ45 COM Port *1,1*COM(9 pins) |
HDMI |
HDMI*1 |
Audio Chipset |
Realtek ALC962 |
USB |
4* USB3.0 |
Mini-PCIE |
Mini-PCIE*1, support 2.4G/5G & WiFi |
DC Jack |
DC Jack*1,12V-9V |
Feature Key |
Power On/Off |
Power Adapter |
Power Adapter |
Input 100V-240V 50/60Hz Output 12V 5A |
Physical Characteristics |
Working Tempeturate |
|
Sotrage Tempeturate |
|
Relative Hnmidity |
|
Remark: |
