N14PDN
Intel I3/I5/I7 8th CPU to 11th CPU:5405U 2C4T Cache 2M 2.30 GHzi3-8145U 2C4T Cache 4M 2.1Ghz~3.9Ghz (TDP:15W)i5-8265U 4C8T Cache 6M 1.6Ghz~3.9Ghz (TD:15W)i7-8565U 4C8T Cache 8M 1.8Ghz~4.6Ghz (TDP: 15W)Intel 11th Gen Tiger lake Processor:i3-1115G1 2C4T Cache 6M 2.2Ghz~3.9Ghz (TDP:28W)i5-1135G7 4C8T Cache 8M 2.4Ghz~4.8Ghz (TD:28W)i7-1165G7 4C8T Cache 8M 1.8Ghz~4.6Ghz (TDP: 28W)
Meegopad-Windows Notebook/MEEGOPAD N14PDN | |
Contact: Elaine Email:elaine@meegopad.cn MB:0086-15889685436 skype:lichen0000lichen1 | |
Specification | www.meegopad.cn www.cew.en.alibaba.com |
General | |
Style | Laptop style |
OS | win10/WIN11 |
Screen | |
Size | 14.1inch |
Touch Screen | |
Resolution | 1920*1080 |
CPU/GPU | |
CPU/GPU | Intel I3/I5/I7 8th CPU to 11th CPU: 5405U 2C4T Cache 2M 2.30 GHz i3-8145U 2C4T Cache 4M 2.1Ghz~3.9Ghz (TDP:15W) i5-8265U 4C8T Cache 6M 1.6Ghz~3.9Ghz (TD:15W) i7-8565U 4C8T Cache 8M 1.8Ghz~4.6Ghz (TDP: 15W)Intel 11th Gen Tiger lake Processor: i3-1115G1 2C4T Cache 6M 2.2Ghz~3.9Ghz (TDP:28W) i5-1135G7 4C8T Cache 8M 2.4Ghz~4.8Ghz (TD:28W) i7-1165G7 4C8T Cache 8M 1.8Ghz~4.6Ghz (TDP: 28W) |
CPU Frequency | |
Turbo Frequency | |
Core | |
GPU | Integrated by CPU |
Storage | |
Ram | Support DDR4 One-Dim slot. Up to 64Gb 2400 to 3200 depends on CPU |
Storage | M.2(2280)NVME SSD(PcIE4) or M.2 Sata3 SSD |
Expand Storage | TF Card Reader/M.2 128GB/256GB/512G/1 TB SSD |
Network Communication | |
WiFi | M.2 slot support Wifi5/Wifi6 Dualbrand. BT4.0/BT5.1 combo in Wifi moduel. |
Bluetooth | BT4.0/5.0 |
I/O Ports | |
Audio port | Realtek |
Card Reader | TF card reader (64G optional) |
USB | 1*USB3.1 type c (USB3.0),2* USB3.0, 1*USB2.0 |
HDMI | HDMI Type A*1 |
Microphone/Audio | 1 |
SSD | M.2 SSD Slot*1 (support sata speed/NVME speed) |
Feature Key | Power On/Off |
Webcam | |
Webcam | 0.3Mega high pixl webcamera |
Speaker | |
Speaker | 8 ohm/1W |
Battery | |
Battery | Li-polymer battery 11.55v4700MAh |
Power Adapter | |
Power Adapter | Input 100V-240V 50/60Hz Output 1*DC-in Plug. 19V/3.42A |
Physical Characteristics | |
Material | AMetal+C+D ABS |
Dimension | 325*214.8*20.9mm/ 625g |
Weight | 625g |
