G10K
Dedicated Graphic 12G/16G Gaming Mini PC Win10/win11/linux
-
Meegopad-Mini PC/MEEGOPAD G10K Contact: Elaine Email:elaine@meegopad.cn Mobile:0086-15889685436 skype: lichen0000lichen1 Style Dedicated Graphic 12G/16G Gaming Mini PC Picture OS Win10/win11/linux CPU Generation Intel 12th/13th gen Core I7 Inte 12th/13th gen Core I5 Intel 12th/13th gen Core I9 Model i7-12700H--I7-13700H i5-12500--I5-13500H i9-12900H--I9-13900H Core 14 12 14 Performance-cores 6 4 6 Efficient-cores 8 8 8 Threads 20 16 20 Max Turbo Frequency 4.70 GHz / 5.00Ghz 4.50 GHz / 4.70Ghz 5.00 GHz / 5.40Ghz TDP 45 W 45 W 45 W Cache 24mb 18 MB 24mb GPU Intel® Iris® Xe Graphics eligible Intel® Iris® Xe Graphics eligible Intel® Iris® Xe Graphics eligible Dedicated Graphic card Model RTX3060 RTX3070 Remark Micro-Architecture NVIDIA AMPERE NVIDIA AMPERE Standard RTX3060, RTX3070 optional Graphics enhanced clock（MHz） 1283-1780MHz 1485MHz Tensor Cores GA106-300 GA104 Process 8nm 8nm CUDA cores 3584 5888 TDP 115W 220W Graphic Memory type GDDR6 GDDR6 Memory Capacity 12GB 16GB Memory Width 192bit 256bit Memory Frequency 1875MHz 14000MHz Ram DDR4 \3200MHz, 2* SO-DIMM SSD M.2 22*80 SSD
PCIE SSDWireless Antenna Support 802.11AX/AC/A/B/G/N optional Dual Antenna Slot M.2 BT BT together with WiFi Module Optional 4.2 to 5.3 Ports USB Ports USB3.2*4 , USB2.0*4 Type C Support DP1.4+USB3.0 HDMI™ 2* HDMI2.0, 2*DP1.4（1* HDMI 1*DP Direct from Nvidia Graphic） Earphone ∮3.5mm 1 LINE OUT 1* MIC in Microphone Digital Microphone*2 RJ45 2.5G LAN Power ∮5.5mm Power connect Diemnsion Dimension 190mm（L）*78mm（W）*220mm（H） Weight 1.2KG Color Sky Gray RBG Colorful RBG
