C3C

Industrial Mini PC Dual Lan 2COM 8USB

Meegopad-Windows Mini PC/MEEGOPAD C3C
Specification	www.meegopad.cn
General
Style	Industrial Mini PC Dual Lan 2COM 8USB
OS	Windows8/10/11/linux
CPU/GPU
cpu	J6412
GPU	Integrated in CPU
Audio	Realtek ALC897
Storage
Ram	DDR4 Singal channel 3200MHZ Max 32GB
Storage	M.2 NVME only1, 2.5inch Sata HDD 3.01
Expand Storage
Network Communication
WiFi	Mini PCIE slot
Lan	Dual Gigabit lan
I/O Ports
RJ45	Gigabit LAN*2 8111H
HDMI	HDMI2 4K Optional HDMI1+VGA*1
VGA	VGA*1 (DP optional)
Audio port/Microphone	Microphone1, Earphone 1
USB	6USB2.0, 2USB3.0
COM	2COM
Feature Key	Power On/Off
Antenna Port	Dual
Inside I/O
F-panel	FP*1
Power on	PWR ON*1 for auto boot
CPU FAN	Slot*1
PWR_IN	1
J_VGA	1
JCMOS	1
Other function
Auto Boot	Support
Wake On Lan	Support
Boot without hardisk	Support
Ontime boot/shutdown	Support
Power Adapter
Power Adapter	Input 100V-240V 50/60Hz Output 12V/3A
Physical Characteristics
Material	All Aluminium Frame; All Aluminium Case for Cooling
Dimension	13412659.2MM
Weight	1.5KG
Color	Silver White/ Black/Customized
Remark: Metal Housing, Suitable size for cooling
